Aluminium Prop Aluminium Props For Sale Aluminium Slab Props
The Leader Prop having infinite prominent features such as Light Weight, Safe, Sturdy and Robust, Compact for logistic and storage, every component has its Key Vantage Features.
Four Start Collar Screw
By employing the four start screw thread for the inner tube adjustment with the cast steel collar screw enables height adjustment of 36mm for each revolution which is 25% faster and 3 times in adjusting efficiency compared to adjustment for conventional steel prop.
Height Indication Tape
Inner tube equipped with indication or measuring tape allowing fast pre-adjustment and reduce labour time spent on measuring and levelling.
Built-in Safe Stopping Device
The prop also provide a safe stopping device to provide the inner tube slide out accidentally during unscrewing adjustment.
Self Cleaning Threading
The inner tube pattern and threading design ensuring self concrete cleaning function and the collar screw running free without jam even at extremely contaminated condition.
Powder Coated Outer Tube
The outer tube are powder coated to avoid concrete adhering.
Specification
| Prop Model | AMP120 | AMP250 | AMP350 | AMP480 | AMP625 |
| L min(mm) | 800 | 1450 | 1980 | 2600 | 4300 |
| L max(mm) | 1200 | 2500 | 3500 | 4800 | 6250 |
| Outer tube length (mm) | 715 | 1365 | 1865 | 2515 | 4211 |
| Inner tube length (mm) | 421 | 1071 | 1571 | 2221 | 1975 |
| Weight kg | 10.9 | 15.5 | 19.3 | 24.3 | 34.1 |
| Min~Max Load KN | 70~90 | 60~70 | 42~88 | 25~85 | 20~56 |
Thanks to the R&D, Leader provides innovative Patented Aluminium Prop & Panel Slab Formwork System with products deflection according to DIN 18202.
Furthermore, Leader's Factory achieved certification with ISO 9001 International Quality Management Standard to evidence and guarantee the Aluminium Prop & Panel Slab Formwork System offers excellent performance with highest safety.
Guangzhou Leader Equipment Ltd. is a manufacturer with enormous experience proven expertise and capabilities in manufacturing and supplying Formwork and Scaffolding Systems. All products have Self Owned Patents, these include Leader’s SGF Superb Formwork System, GN50 Omni Scaffolding System, AMP Aluminium Prop & Panel Slab Formwork System, FRP Fiberglass Mobile Scaffold Towers, Aluminium Protection Net System, and also Personnel Access Equipment etc.
Our scaffold and formwork will be strictly inspected before packing and shipping out to insure that they could be satisfied with you.
The light weight robust prop ensuring easy transportation, faster erection, high efficiency, low labour and stowing charge, provide larger & wider operation space on site, providing extremely cost effective for construction utilization.
Q: Are you a factory or trading company?
A: Professional Factory
Q: Where is your factory located? How can I visit there?
A: Leader is located in Guangzhou City, China, It takes only 40 minutes drive from Bai Yun International Airport. You are welcome to visit us!
Q: What is your product range?
A: Guangzhou Leader Equipment Ltd. is a manufacturer specialize in professional design and production of GN50 Aluminum & Steel Scaffold, Fiberglass Scaffolding, Aluminum Shoring & Slab Panel Formwork System, Superb Formwork System and Aerial Working Platforms etc.
Q: Do you accept OEM?
A: OEM is acceptable.
Q: What Payment terms do us accept?
A: T/T in advance (100%, 30% deposit+70% before shipment), LC.
