| Brand Name: | LEADER |
| Model Number: | 460 |
| Price: | $800.00/sets >=1 sets |
| Supply Ability: | 60 Set/Sets per Month scaffold platform ladder |
EN1004 Standard Aluminium Ladder Frame Scaffolding Perfect For Building Construction
Leader Mobile Aluminium Scaffold Tower has been design, prefabricated and manufacturer to be fully complying with the stringent European standard EN1004 with CE Certification for mobile tower, all towers are suitable for indoor and outdoor applications.
|
Product Name: |
Leader Aluminium Mobile Scaffold Tower |
|
Scaffolding Type: |
Ladder Frame Mobile Scaffold |
|
Place of Origin: |
Guangzhou China |
|
Material |
Aluminum Alloy 6082-T6 |
|
Main Tube |
Tube Wall Thickness: 1.6MM, 3.2MM; Pipe Diameter: 50.6MM |
|
Size(WxL) |
075m(W)*2.0m/2.5m/3.0m(L); 1.35m(W)*2.0m/2.5m/3.0m(L) |
|
Height |
2-20m |
|
Floors |
3 floor,4floor,5floor is up to you |
|
Colour |
Silver |
|
Load Capacity |
200kg/sqm |
|
Certification |
CE Certification |
|
Standard |
EN1004 |
|
Application |
Used in making advertising, painting ceiling, building construction, cleaning, repairing |
|
Type |
Single Width Laddaspan Towers |
Double Width Laddaspan Towers |
45°Stairway Tower
|
|
Size |
Dimensions: 075m(W)*2.0m/2.5m/3.0m(L) |
Dimensions: 1.35m(W)*2.0m/2.5m/3.0m(L) |
Dimensions: 1.35m(W)*2.0m/2.5m/3.0m(L) |
|
Application |
*Suitable for working in limited space. *Easy to access through standard doorways & corridors. * Easy to assemble even applying on escalators or stairways. * Light & compact enough to stow in small vans & trucks.
|
* Suitable for construction & industrial usages. * Vertical ladder structure provides maximum work space & reduces erection time. * Proper combination of design with greater flexibility and maximizing utilization. * Platform can be placed at any rung of the frames, distance between each rung is 460mm. |
* Integral stairway and hand rall system. * Ideal for frequent ascents and descent inside the tower. * Convenient for tools and material trasportation.
|
1. Easy assemble and dismantle, can be used both independent set and large structures widely used for elevator, the staircase, building site, etc.
2. The frame components are constructed by high quality T6082-T6 aircraft aluminium with high yield stress and strain to resist strong impact force.
3. Build-in ladder could supply more working space, reducing assemble time.
4. Platform can be placed at any height of the frame.
5. All leaders available in custom made special dimension.
6. Leader aluminium scaffold has folding base, could expand and storage quickly to reduce time and improve efficiency. Leader could supply both single and double width folding scaffold.
EN1004 Design & CE Certification
Leader Aluminium Scaffold Tower has acquired CE Certification compliance with European Standard EN1004. Leader's factory also achieved certification with ISO 9001 International Quality Management Standard to evidence and guarantee this unique aluminium mobile scaffold tower system offering excellent safe quality & stable performance.
Guangzhou Leader Equipment Ltd. is a manufacturer with enormous experience proven expertise and capabilities in manufacturing and supplying Formwork and Scaffolding Systems. All products have Self Owned Patents, these include Leader’s SGF Superb Formwork System, GN50 Omni Scaffolding System, AMP Aluminium Prop & Panel Slab Formwork System, FRP Fiberglass Mobile Scaffold Towers, Aluminium Protection Net System, and also Personnel Access Equipment etc.
Packaging & Shipping
Our scaffold and formwork will be strictly inspected before packing and shipping out to insure that they could be satisfied with you.
1. Guangzhou Leader Equipment Co. Ltd was founded in 1999, and is one of the earliest and professional aluminium scaffold manufacturer in China.
2. Strong professional technical team and design team ensure to produce scaffolding with top quality.
3. Rich experience on manufacture field with more than 20 years export exprience.
4. We provide OEM, ODM service, you could let us know all requirements, our design team and technical team will produce them according to your requirements.
5. We provide samples service.
Licenses and Qualify
Q: Are you a factory or trading company?
A: Professional Factory
Q: Where is your factory located? How can I visit there?
A: Leader is located in Guangzhou City, China, It takes only 40 minutes drive from Bai Yun International Airport. You are welcome to visit us!
Q: What is your product range?
A: Guangzhou Leader Equipment Ltd. is a manufacturer specialize in professional design and production of GN50 Aluminum & Steel Scaffold, Fiberglass Scaffolding, Aluminum Shoring & Slab Panel Formwork System, Superb Formwork System and Aerial Working Platforms etc.
Q: Do you accept OEM?
A: OEM is acceptable.
Q: What Payment terms do us accept?
A: T/T in advance (100%, 30% deposit+70% before shipment), LC.
